XDM6000 Series 6½-Digit Digital Multimeter
- True 6½-digit resolution with up to 2,200,000 counts
- Wide measurement range up to 3000 V DC and 300 A DC
- High-speed measurement up to 10,000 readings/s
- True RMS AC voltage and current measurement
- Resistance measurement up to 100 MΩ
- Capacitance measurement up to 100 mF
- Frequency and period measurement up to 1 MHz
- Temperature measurement with thermocouple, RTD, and thermistor support
- Built-in thermocouple cold-junction compensation
- Advanced math functions including Min, Max, Average, Standard Deviation, dB, dBm, Limit, Histogram, Trend Chart, and Bar Chart
- Data logging with intervals from 1 ms to 3600 s
- Internal logging capacity of up to 2M points
- 2 GB NAND Flash storage
- USB Host, USB Device, LAN, and RS-232 interfaces
- SCPI support for automated test and measurement systems
- 4.3-inch IPS touchscreen display
The XDM6000 Series includes the XDM6061, XDM6061-H, and XDM6051 models. The XDM6061 and XDM6061-H provide true 6½-digit resolution with up to 2,200,000 counts, while the XDM6061-H extends the DC voltage measurement range to 3000 V and DC current range to 300 A. The instruments support DC and True RMS AC voltage and current, resistance, capacitance, frequency, diode, continuity, and temperature measurements. Temperature measurement supports B, E, J, K, N, R, S, and T thermocouples, Pt100 and Pt385 RTDs, and 5 kΩ thermistors. Advanced mathematical functions include Min, Max, Average, Standard Deviation, dB, dBm, Limit testing, Histogram, Trend Chart, and Bar Chart. The data logger supports intervals from 1 ms to 3600 s with up to 2M internal measurement points. LAN, USB Host, USB Device, and RS-232 interfaces, together with SCPI commands, enable integration into automated test systems.
| Models | Available Models | XDM6061, XDM6061-H, XDM6051 |
| Display | Resolution | 6½ digits, up to 2,200,000 counts |
| Display | 4.3-inch IPS LCD touchscreen | |
| DC Voltage | Measurement Range | 200.0000 mV–1000.000 V (XDM6061); 200.0000 mV–3000.000 V (XDM6061-H); 200.000 mV–1000.00 V (XDM6051) |
| AC Voltage | True RMS AC Voltage | 200.0000 mV–750.0000 V (XDM6061/XDM6061-H); 200.000 mV–750.000 V (XDM6051) |
| DC Current | Measurement Range | 200.0000 μA–10.00000 A (XDM6061); 200.0000 μA–300.00000 A (XDM6061-H); 200.000 μA–10.0000 A (XDM6051) |
| AC Current | True RMS AC Current | 200 μA–10 A |
| Resistance | Measurement Range | 200.0000 Ω–100.0000 MΩ |
| Diode | Diode Test | 0–5 V |
| Continuity | Continuity Test | Up to 2000.0 Ω |
| Frequency | Frequency / Period | 3 Hz–1 MHz |
| Capacitance | Measurement Range | 2.0000 nF–100.00 mF |
| Temperature | Temperature Measurement | B/E/J/K/N/R/S/T thermocouples; Pt100 and Pt385 RTDs; 5 kΩ thermistors |
| Measurement | Maximum Measurement Speed | Up to 10,000 readings/s |
| Mathematics | Math Functions | Min, Max, Average, Standard Deviation, dBm, dB, Limit, NULL, Histogram, Trend Chart, Bar Chart |
| Data Logging | Logging Interval | 1 ms–3600 s |
| Internal Logging Capacity | 2M measurement points | |
| Storage | Internal Storage | 2 GB NAND Flash |
| Connectivity | Communication Interfaces | LAN, USB Device, USB Host, RS-232 |
| Control | Remote Control | SCPI supported |
| Trigger | Trigger | External Trigger, VMC Out |
| Mechanical | Dimensions | XDM6061-H: 109 × 226 × 346 mm; XDM6061/XDM6051: 109 × 226 × 320 mm |
| Weight | Approximately 3.5 kg |
