OWON 2CH 12-bit XDS2102A Economical Digital Oscilloscope
- 2-channel oscilloscope with 100MHz bandwidth
- 12-bit high-resolution ADC for accurate waveform detail (16× better than 8-bit)
- Real-time sampling rate up to 1 GS/s
- 20M record length for extended waveform capture
- Waveform refresh rate up to 55,000 wfms/s
- Low background noise for precise small signal measurement
- Vertical sensitivity from 1mV/div to 10V/div
- Standard serial bus decoding: I2C, SPI, RS232, CAN
- Multiple trigger modes including Edge, Pulse, Slope, Runt, Window, Timeout, Logic
- SCPI and LabVIEW support for remote control and automation
- Ultra-thin compact design for space-saving
- Rich interfaces: USB Host, USB Device, LAN, VGA (optional), AUX, PictBridge
- 8-inch 800×600 high-resolution LCD display
Need a custom configuration?Our engineers are ready to help spec the right solution.
Overview
The XDS2102A stands out with its 12-bit ADC, delivering significantly higher precision compared to standard 8-bit oscilloscopes. It allows detection of very small signal changes down to 1mV, making it perfect for noise-sensitive measurements. With built-in protocol decoding and a compact design, it provides excellent value for professionals and educational use.
Specifications
| Oscilloscope | Model | XDS2102A |
| Bandwidth | 100MHz | |
| Sample Rate | 1 GS/s | |
| Vertical Resolution | 12-bit ADC | |
| Record Length | 20M | |
| Channels | 2 + 1 External | |
| Horizontal Scale | 2ns/div – 1000s/div (1-2-5 step) | |
| Performance | Waveform Refresh Rate | 55,000 wfms/s |
| Vertical Sensitivity | 1mV/div – 10V/div | |
| Noise Performance | Low noise (~3 divisions at 1mV/div) | |
| Display | Screen | 8-inch LCD, 800 × 600 resolution |
| Trigger | Trigger Types | Edge, Video, Pulse, Slope, Runt, Window, Timeout, Nth Edge, Logic, I2C, SPI, RS232, CAN |
| Decoding | Bus Decode | I2C, SPI, RS232, CAN (standard) |
| Interfaces | Connectivity | USB Host, USB Device, LAN, VGA (optional), AUX, PictBridge, Trigger Out |
| Software | Remote Control | SCPI, LabVIEW supported |
| Power | Supply | 100V – 240V AC, 50/60Hz, CAT II |
| Battery | Not supported | |
| Physical | Dimensions | 340 × 177 × 90 mm |
| Weight | Approx. 2.6 kg |
