OWON ODP3032 2-CH Programmable DC Power Supply
Programmable DC Series

OWON ODP3032 2-CH Programmable DC Power Supply

  • Two independent controllable channels + Fixed 5V output
  • Output resolution: 1mV / 1mA
  • Low ripples / low noise: <300 μVrms / 2 mVpp
  • Up to 100 group timers
  • Up to 10 group preset system configurations
  • Over-voltage / Over-current protection
  • 3.9 inch high resolution (480 x 320 pixels) TFT LCD
  • Multiple communication interface: USB and RS232
Need a custom configuration?Our engineers are ready to help spec the right solution.
Overview

With a total output power of 195W, the ODP3032 provides two independently controllable 30V/3A channels plus a fixed 5V/3A channel. It features industry-leading low noise and ripple specifications, ensuring minimal interference with sensitive electronics. The large color LCD makes it easy to monitor and configure all channels simultaneously.

Specifications
OutputCH1/CH20-30V / 0-3A
Fixed Channel5V / 3A
PrecisionSetting Resolution1mV / 1mA
NoiseRipple (CV)≤300μVrms / 2mVpp
PhysicalWeight10.50 kg
