OWON HSA1015 / HSA1032 Handheld Spectrum Analyzer
- Frequency range from 9 kHz to 1.5 GHz / 3.2 GHz
- Ultra-low noise floor down to -160 dBm
- Phase noise performance up to -82 dBc/Hz
- Minimum 10 Hz RBW for detailed signal analysis
- Amplitude accuracy < 1.5 dB
- EMI pre-compliance test support
- 8-inch IPS touchscreen display
- Portable with 4–6 hours battery life
- Tracking generator support (model dependent)
Need a custom configuration?Our engineers are ready to help spec the right solution.
Overview
The HSA1015 / HSA1032 series provides a cost-effective solution for RF engineers and technicians who require portable spectrum analysis tools. With up to 3.2 GHz coverage, these devices are suitable for wireless communication testing, EMI troubleshooting, and general RF measurements. Their high sensitivity (-160 dBm), intuitive touchscreen interface, and tracking generator functionality make them ideal for both lab and field applications.
Specifications
| Models | Variants | HSA015-TG (1.5GHz), HSA032-TG (3.2GHz) |
| Frequency | Range | 9 kHz – 1.5 GHz / 3.2 GHz |
| Resolution | 1 Hz | |
| Span | 0 Hz, 100 Hz to max frequency | |
| Bandwidth | RBW | 10 Hz – 500 kHz, 1 MHz, 3 MHz |
| VBW | 10 Hz – 3 MHz | |
| Phase Noise | @1GHz offset 10kHz | < -80 dBc/Hz (typical) |
| Amplitude | Range | DANL to +20 dBm |
| Accuracy | < 1.5 dB | |
| Noise Level | DANL (Preamp ON) | Up to -160 dBm |
| Tracking Generator | Range | 100 kHz – 1.5 GHz / 3.2 GHz |
| Output Level | -40 dBm to 0 dBm | |
| Display | Screen | 8-inch TFT LCD (1024 × 768) |
| Connectivity | Interfaces | USB Host, USB Device, LAN |
| Battery | Operating Time | 4–6 hours |
| Physical | Dimensions | 265 × 190 × 58 mm |
| Weight | Approx. 2.5 kg |
