OWON DGE3000 Series Arbitrary Waveform Generator
Dual Channels

OWON DGE3000 Series Arbitrary Waveform Generator

  • Dual-channel arbitrary waveform generator
  • Frequency output up to 60MHz
  • High sample rate up to 300MSa/s
  • 14-bit vertical resolution for high accuracy
  • Large arbitrary waveform length up to 100K points
  • 5 standard waveforms and 160 built-in arbitrary waveforms
  • Advanced modulation: AM, FM, PM, PWM, FSK, 3FSK, 4FSK, PSK, ASK, BPSK, QPSK, DSB-AM, Sweep, Burst
  • High frequency resolution up to 1μHz
  • SCPI support for remote control and automation
  • 3.6-inch LCD display (480 × 272)
  • External modulation, trigger, and reference clock support
Need a custom configuration?Our engineers are ready to help spec the right solution.
Overview

The DGE3000 Series extends waveform generation capabilities with higher memory depth and advanced digital modulation options. With up to 60MHz frequency output and 300MSa/s sample rate, it supports precise signal synthesis. The extended 100K waveform length allows more detailed waveform creation, making it ideal for communication systems, embedded development, and advanced testing environments.

Specifications
ModelsDGE3032, DGE3062
Channels2
PerformanceFrequency Output30MHz / 60MHz
Sample Rate125MSa/s / 300MSa/s
Vertical Resolution14-bit
Waveform Length2 – 100K points
WaveformsStandardSine, Square, Pulse, Ramp, Noise
Arbitrary160 built-in + user-defined waveforms
FrequencyRange1μHz – 60MHz (model dependent)
Resolution1μHz
AmplitudeOutput Range1mVpp – 10Vpp (≤10MHz), 1mVpp – 5Vpp (≤60MHz)
Load Impedance50Ω (typical)
OffsetDC Offset Range±10Vpk (High-Z), ±5Vpk (50Ω)
Resolution1mV
ModulationTypesAM, FM, PM, PWM, FSK, PSK, QPSK, ASK, BPSK, Sweep, Burst, and more
MeasurementFrequency CounterFrequency, Period (100mHz – 200MHz)
InterfacesConnectivityUSB Host, USB Device
External I/OExternal modulation input, trigger input, reference clock I/O
DisplayScreen3.6-inch LCD (480 × 272)
PhysicalDimensions200 × 92 × 157 mm
WeightApprox. 0.8 kg
