OWON CP-07+ AC/DC Clamp Current Probe
- High-precision low-current measurement: 400mA to 4A
- Supports both AC and DC current measurement
- High bandwidth up to 1MHz (±3dB)
- Fine resolution of 0.1mA for accurate readings
- Compact jaw size (5mm) for tight spaces
- Auto-zero function at power-on
- High sensitivity output (1mV/1mA and 1mV/10mA)
- Battery powered (9V) for portability
- Compatible with oscilloscopes via standard interface
- Lightweight and ergonomic clamp design
Need a custom configuration?Our engineers are ready to help spec the right solution.
Overview
The CP-07+ clamp current probe is ideal for measuring small AC/DC currents with high accuracy and minimal noise. With its 1MHz bandwidth and high sensitivity, it is suitable for analyzing fast-changing signals in electronic circuits. Its compact jaw size allows access to tight measurement points, while auto-zero functionality ensures stable and reliable readings.
Specifications
| Model | CP-07+ | |
| Measurement Type | AC/DC Current | |
| Range | 400mA – 4A | |
| Resolution | 0.1mA | |
| Bandwidth | DC – 1MHz (±3dB) | |
| Jaw Size | 5mm (max) | |
| DC Measurement | Ranges | 400mA, 4A |
| Accuracy | ±1.5% rdg ±5 digits | |
| Sensitivity | 1mV/1mA, 1mV/10mA | |
| AC Measurement | Ranges | 400mA, 4A |
| Accuracy | ±2.0% rdg ±5 digits | |
| Sensitivity | 1mV/1mA, 1mV/10mA | |
| Power | Supply | 9V (6F22) battery |
| Environment | Operating Temperature | 0°C to 50°C |
| Humidity | 15% – 70% RH | |
| Physical | Dimensions | 215 × 36 × 58 mm |
| Weight | Approx. 200 g |
